Features & Benefits

  • Ideal for general commercial use and point-of-use applications like eyewash stations, or used as a booster
  • 50, 85, 120 and 175 gallon models available
  • Inputs: 3 through 108 kW
  • Voltages: 208, 240, or 480 VAC in either single phase or 3-phase; 277 VAC single phase
  • Element wattages: 2000, 3000, 4000, 4500, 5000 and 6000 in the four voltages; 9000 watt element at 480 VAC
  • Available in 1, 3, 6, 9 or 12 element configurations for your specific kW application
  • Elements are Lifeguard™ stainless steel, screw-in type that resist burnout and corrosion
  • ASME construction is available on E50, E85 and E120 models and comes standard on E175 model
  • Long life tank design: proprietary steel formulation with high temperature glass lining to maximize corrosion resistance resulting in a superior tank design
  • Two anode rods are installed to ensure long life and corrosion resistance

Efficiency

  • 98% thermal efficiency
  • Thick foam insulation for minimal standby heat loss

Performance

  • Recovery rate: Up to 438 gallons GPH at a 100 degree rise
  • Up to 190° F maximum delivered temperature for E series; 181° F for ES50, ES85 and ES120

Capacity & Shipping Weight

  • 50 Gal/270 lbs./320 lbs. ASME
  • 85 Gal/350 lbs./380 lbs. ASME
  • 120 Gal/430 lbs./460 lbs. ASME
  • 175 Gal/700 lbs. ASME only
Easy Installation & Service

  • Control box is located at the front of unit for easy wiring during installation– Multiple knockout holes accommodate a variety of conduit sizes
  • Exclusive! System Sentinal™ provides a diagnostic panel with LEDs that correspond to the number, location and status of each element
  • Exclusive! Full-port, full-flow, brass drain valve for faster draining
  • Minimum distance to combustible is zero inches from jacket and 18 inches from access door
  • All models approved for installation on combustible flooring

Plus

  • Temperature and pressure relief valve at top of 175 gallon model and side on all other models
  • Water connections: hot and cold water inlets are 2-1/2" NPT dielectric nipples on the 175 gallon model and 1-1/2" on all other models

Specifications

  • 50, 85, 120 & 175-Gallon Capacities
  • ASME Construction Option
  • 3-Year Limited Warranty
  • Electric

Certifications

LWHULAHRIClassfied UL with Optional KitElectric

Documents

Heavy Duty (6 - 54 KW)

Warranties

  • 3-Year limited tank warranty
  • 1-year limited parts warranty
